Rough Terrain Scissor Lift

Qhov siab tshaj plaws ua haujlwm siab yog 14m, siv lub tshuab crawler, siab zog manganese steel, roj teeb lub zog (lub zog diesel yog xaiv tau), thiab qhov siab tshaj plaws yog 450kg. Rough terrain scissor nqa muaj zog adaptability rau ib puag ncig, crawler log, haum rau taug kev ntawm av nkos txoj kev nyob rau hauv cov qus thiab high-altitude ua hauj lwm Nws yog ib tug zoo tagnrho cov cuab yeej rau high-altitude kev khiav hauj lwm xws li sab nraum zoov installation thiab kev tsim kho.

Xa kev nug

Tsham tam sim no

Hauj lwm lawm

Rough Terrain Scissor Lift muaj ntau yam kev siv thiab tau siv dav hauv cov chaw tsim kho, tsev so, warehouses, tshav dav hlau, chaw nres tsheb, docks, chaw ntau pob thiab lwm lub tsev siab rau cov khoom siv siab siab, kev tu thiab tu, cov kav dej siv hluav taws xob sab nraum zoov. , thiab lwm yam. Nws yog ua kom muaj kev nyab xeeb thiab txhim kho kev ua haujlwm. Cov cuab yeej zoo tshaj plaws rau kev ua haujlwm zoo, ua rau huab cua ua haujlwm yooj yim dua thiab sai dua. Lub kaw lus hydraulic ntawm txiab hom hydraulic nqa khoom feem ntau yog nruab nrog kev ruaj ntseg txij nkawm xws li tiv thaiv lub caij nplooj zeeg, overload thiab lub zog tsis ua haujlwm. Lwm qhov tshwj xeeb ruaj khov nqa kuj tseem muaj cov khoom tawg-pov thawj hluav taws xob uas tsim nyog siv rau hauv qhov chaw tawg-pov thawj. Kev taw qhia lub log, rail-hom sab nraud lub hwj chim chav tsev, siv chains lossis crossbars rau kev nkag thiab tawm ntawm lub rooj, guardrails thiab nqa lub rooj ua haujlwm ceeb toom teeb lossis ceeb toom tswb, kev nyab xeeb hloov uas kaw lub rooj sib tham thaum lub qhov rooj qhib, thiab ntau lwm yam haujlwm. Nws yog qhov yooj yim heev rau cov neeg ua haujlwm tswj hwm txhua txheej ua haujlwm ntawm ntau lub ntsiab lus, thiab ua haujlwm hauv kev khiav haujlwm lossis kev nyab xeeb.

Hom qauv	Qauv TSIS MUAJ: CL-TC04	Qauv TSIS MUAJ: CL-TC06	Qauv TSIS MUAJ: CL-TC06H	Qauv TSIS MUAJ: CL-TC08	Qauv TSIS MUAJ: CL-TC08H	TXL-TC 10	CL-TC 10 H	TXL-TC12	Qauv TSIS MUAJ: CL-TC12H
Tsis Siv Neeg Leveling Hydraulic Outriggers	Tsis muaj	Tsis muaj	Nruab	Tsis muaj	Nruab	Tsis muaj	Nruab	Tsis muaj	Nruab
Ua haujlwm siab	6.5m	8m	8m	10m	10m	12m	12m	14m	14m
Max.lifting qhov siab	4.5m	6m	6m	8m	8m	9.75m	9.75m	11.75m	11.75m
Load Capacity	200 Kg	450 Kg	450 Kg	450 Kg	450 Kg	320 Kg	320 Kg	320 Kg	320 Kg
Extendable Platform	100 Kg	113 Kg	113 Kg	113 Kg	113 Kg	113 Kg	113 Kg	113 Kg	113 Kg
Cov neeg ua haujlwm ntawm Platform	1	2	2	2	2	2	2	2	2
Zuag qhia tag nrho ntev	1.27	2.47	2.782	2.47	2.782	2.47	2.782	2.47	2.782
Dav dav	0.79	1.39	1.581	1.39	1.581	1.39	1.581	1.39	1.581
Tag Nrho Qhov Siab (Guardrails nthuav tawm)	1.82	2.28	2.28	2.7	2.4	2.53	2.53	2.67	2.67
Tag Nrho Qhov Siab (Guardrails folded))	/	1.745	1.745	1.865	1.865	1.995	1.955	2.13	2.13
Platform Loj (m)	1.23*0.655	2.271.120.7	2.271.120.7	2.271.120.7	2.271.120.7	2.271.120.7	2.271.120.7	2.271.120.7	2.271.120.7
Extendable Platform (m)	0.55	0.9	0.9	0.9	0.9	0.9	0.9	0.9	0.9
Min Hloov Radius (m)	0	0	0	0	0	0	0	0	0
Min Av Clearance (m)	0.05	0.15	0.15	0.15	0.15	0.15	0.15	0.15	0.15
Lifting Tsav	24v / 0.1.2Kw	48V / 4 Kw	48V / 4 Kw	48V / 4 Kw	48V / 4 Kw	48V / 4 Kw	48V / 4 Kw	48V / 4 Kw	48V / 4 Kw
Tsav Tsav	2 x 24v/1.5Kw	2 x 48v/4Kw	2 x 48v/4Kw	2 x 48v/4Kw	2 x 48v/4Kw	2 x 48v/4Kw	2 x 48v/4Kw	2 x 48v/4Kw	2 x 48v/4Kw
Tsav ceev	1.7 Km/h	2.4 Km / h	2.4 Km / h	2.4 Km / h	2.4 Km / h	2.4 Km / h	2.4 Km / h	2.4 Km / h	2.4 Km / h
Lifting up/down Ceev	24/20 sec	38/30 sec	38/30 sec	45/36 sec	45/36 sec	70/62 s. : kuv	70/62 s. : kuv	85/75 sec	85/75 sec
Charger	0.25	48V/25A	48V/25A	48V/25A	48V/25A	48V/25A	48V/25A	48V/25A	48V/25A
Tshuab hnyav	7 90kq	2400 Kg	2800 Kg	2550 Kg	2 950kg	2 840kg	3 240kg	3000 Kg	3 480kg
Optional 1>	Teb chaws USA Trojan roj teeb
Optional 2>	Phau ntawv outrigger: (tsuas yog muaj rau hom crawler)
Optional 3>	Diesel zog, thov nug peb
