Lub Hydraulic Tsav Self Propelled Scissor Lift Platform los ntawm CATHAYLIFT - Lub Pinnacle ntawm Versatility thiab Efficiency nyob rau hauv elevated Work Solutions.
Cov cuab yeej siv niaj hnub no tau dhau qhov kev txwv nrog nws txoj kev sib koom ua ke ntawm kev ua tau zoo, kev nyab xeeb, thiab yooj yim. Tsim los ua kom zoo li "tus neeg siv dav dav," nws txoj kev txav plaub-log muaj qhov tsis sib xws, ua rau nws tseem tsis tau muaj nyob thoob plaws ntau qhov kev lag luam. Txawm hais tias navigating lub confines ntawm cov chaw nres tsheb roj los yog qhov nthuav dav ntawm cov chaw ua si kis las, lub platform no yoog tau yooj yim rau ntau qhov chaw ua haujlwm, txhawb cov neeg siv los daws cov haujlwm siab tshaj plaws nrog kev ntseeg siab thiab raug.
|
Qauv No. |
Loading peev (kg) |
Lifting qhov siab (m) |
Platform Loj (m) |
Zuag qhia tag nrho |
Lifting Time(s) |
Qhov hluav taws xob |
Lub cev muaj zog |
Log (φ) |
Net Nyhav (kg) |
|
TIAB SA 0406 |
450 |
6 |
1.85*0.88 |
1.95*1.08*1.1 |
55 |
TIAB SA 380 |
1.5 |
200 PAB |
800 |
|
TIAB SA 0407 |
450 |
7.5 |
1.8*1.0 |
1.95*1.2*1.54 |
60 |
TIAB SA 380 |
1.5 |
400-8 Roj hmab |
1000 |
|
TIAB SA 0409 |
450 |
9 |
1.8*1.0 |
1.95*1.2*1.68 |
70 |
TIAB SA 380 |
1.5 |
400-8 Roj hmab |
1200 |
|
TIAB SA 0411 |
450 |
11 |
2.1*1.15 |
2.25*1.35*1.7 |
80 |
TIAB SA 380 |
2.2 |
500-8 Roj hmab |
1580 |
|
TIAB SA 0412 |
450 |
12 |
2.45*1.35 |
2.5*1.55*1.88 |
125 |
TIAB SA 380 |
3 |
500-8 Roj hmab |
2450 |
|
TIAB SA 0414 |
450 |
14 |
2.45*1.35 |
2.5*1.55*2.0 |
165 |
TIAB SA 380 |
3 |
500-8 Roj hmab |
2650 |
|
TIAB SA 1006 |
1000 |
6 |
1.8*1.0 |
1.95*1.2*1.45 |
60 |
TIAB SA 380 |
2.2 |
500-8 Roj hmab |
1100 |
|
TIAB SA 1009 |
1000 |
9 |
1.8*1.25 |
1.95*1.45*1.75 |
100 |
TIAB SA 380 |
3 |
500-8 Roj hmab |
1510 |
|
TIAB SA 1012 |
1000 |
12 |
2.45*1.35 |
2.5*1.55*1.88 |
135 |
TIAB SA 380 |
4 |
500-8 Roj hmab |
2700 |
|
TIAB SA 0316 |
300 |
16 |
2.75*1.5 |
2.85*1.75*2.1 |
173 |
TIAB SA 380 |
3 |
500-8 Roj hmab |
3200 |
Khoom Paub meej:
Txheej txheem cej luam
Txheej txheem cej luam
Txheej txheem cej luam
Platfrom Nrog Guardrail
Control Vaj Huam Sib Luag (Ib Lub Platform)
Tswj vaj huam sib luag (hauv av)
Ladder Yooj yim rau Climp
Siab Gauges & Thaum Muaj Xwm Ceev Ncua Valve
Hydraulic Pump Chaw Nres Tsheb
Lub zog loj
Qhov taw qhia Leveling
Txhawb nqa ceg
Roj teeb (yeem)
Tool lub thawv
Roj Hmab Log
Qhov zoo:
● Kev Mobility ntau yam:
Ua raws li qhov tseeb "generalist," Hydraulic Driven Self Propelled Scissor Lift Platform boasts plaub lub log txav, kom ntseeg tau tias tsis muaj kev sib tw. Los ntawm cov chaw nres tsheb roj mus rau cov chaw ua kis las, nws qhov kev hloov pauv tau paub tsis muaj kev cia siab, ua rau muaj kev sib txawv ntawm qhov chaw ua haujlwm tau yooj yim.
●Kev tsim kho muaj zog:
Crafted nrog high-strength manganese steel kav, lub Hydraulic Tsav Self Propelled Scissor Lift Platform piv txwv durability thiab kev ntseeg tau. Nws cov qauv tsim compact tab sis ruaj khov lav kev ruaj ntseg, txhawb nqa qhov siab tshaj plaws ntawm 1500kg thiab ncav cuag qhov siab ua haujlwm siab ntawm 18m. Nrog qhov ntev ntawm 2816 * 1600mm thiab qhov hnyav ntawm 3400kg, nws sawv ua lub teeb pom kev ntawm lub zog hauv qhov chaw ua haujlwm.
●Txhim khu kev ua tau zoo:
Nruab nrog polyurethane log, peb Hydraulic Tsav Self Propelled Scissor Lift Platform ua kom cov kev taw qhia du yam tsis muaj kev puas tsuaj rau qhov chaw mos. Siv Delixi hom hluav taws xob cov khoom siv hluav taws xob thiab 24v kev nyab xeeb fais fab mov, nws tseem ceeb rau cov neeg siv kev nyab xeeb thaum xa khoom zoo ib yam. Cov detachable guardrails ntxiv ib txheej ntxiv ntawm kev ruaj ntseg, txhim khu usability yam tsis muaj kev cuam tshuam kev nyab xeeb.
●Cov neeg siv-phooj ywg ua haujlwm:
Txaus siab rau nws txoj kev yooj yim thiab kev ruaj ntseg, kev khiav hauj lwm Hydraulic Tsav Self Propelled Scissor Lift Platform yog ib qho yooj yim. Nrog rau nruab nrab ceev thiab seamless switching, cov neeg siv muaj ib theem ntawm kev tswj uas txhawb kev ntseeg siab thiab efficiency. Nws yog ib qho pov thawj rau peb txoj kev cog lus rau kev xa cov khoom uas tsis yog tsuas yog ua tau raws li cov neeg siv khoom xav tau xwb.
Kev txiav txim tiag:
